Gn15 Track

Postby KEG » Sat May 16, 2009 8:36 pm

Hi,

There were different methods described in this forum, how to make suitable Gn15 track. The easiest way is to bury HO or 0-16,5 track in the ground with ballast or grass, so you can´t see the sleepers.

recently I received some Micro Engineering 0n30 track. It is quite popular in the US. The sleepers are 38 or 39 mm long and about 3mm wide. You can remove the conection between the ties and push 2 together, to form a wider tie.




I placed them approx 30 mm apart for my needs.




The track is a bit lower (Code 83) than Peco´s Code 100. The switches need a few strokes with a file for some drives, e.G. the Fleischmann Magic Train, to pass.

I don´t know, if somebody stocks them in the UK. I bought mine in Germany:
http://www.ks-modelleisenbahnen.de/html/microengineering.html

Have Fun

Juergen

User avatar
chris69
Demi-Millegniumer
Demi-Millegniumer
Posts: 561
Joined: Sat Aug 11, 2007 7:06 pm
Location: BERLIN Germany
Interests: any thing with narrow gauge and quarries

Postby chris69 » Sun May 17, 2009 6:46 am

Hallo Juergen,
klasse Idee!

Well there is a reasonable solution.Do you think it will work with the PECO On30 track?That is easy to get in the US.
And it would definitely look a lot better then the standard time consuming HO method.

Schoenen Sonntag

Chris 8)
It's my RR and it exists,in my mind!!!!!!!!

User avatar
AndyA
Demi-Millegniumer
Demi-Millegniumer
Posts: 887
Joined: Tue Dec 30, 2003 12:24 am
Location: Southampton, England
Interests: Railways, Folk music, food, travel
Andy died 14-Sep-2017 and will post no more. Travel well on your new guage.

Postby AndyA » Sun May 17, 2009 6:55 am

Do you think it will work with the PECO On30 track?


I haven't tried it for real, yet (might get time later), but close examination of a length of 016.5 flex I have here suggests that the 'rustic' ends of he sleepers/ties is more pronounced than on Juergen's Micro-Engineering track, so the ends of some pairs may look a bit odd.

regards
Andy A
Gn15: Gnot so much a scale, more a state of mind
gnine: less is the gnew more
GnTonic - enjoy irresponsibly

User avatar
KEG
Millegniumer
Millegniumer
Posts: 1248
Joined: Mon Feb 06, 2006 11:42 am
Location: Duesseldorf
Interests: creative Nonsense

Postby KEG » Sun May 17, 2009 9:42 am

Hi,

There are a few suggestons for working with Peco track here: http://forum.gn15.info/viewtopic.php?p=4996#4996

The 0-16,5 / 0n30 / 0e Peco track sleepers are approx 32mm long. Using them in pairs mike look a bit strong. You can always work on gaps with some filler.
I tried on a little piece with removing every second tie:


Peco track is on the left in the above example. Used coffee from my filter as ballast on the right track. The grain is a bit fine, but I like the colour.

Have fun

Juergen

User avatar
Bilco
Millegniumer
Millegniumer
Posts: 1033
Joined: Mon Oct 29, 2007 3:55 pm
Location: Woodstock, Oxfordshire
Interests: 7mm & 16mm NG, Gn15

Gn15 Track

Postby Bilco » Sun May 17, 2009 10:31 am

Hi Juergen,

I used the Peco track with the sleepers supplied, but spaced them out a bit - 3 in the space originally taken by 4 seemed about right

Bill

If at first you don't succeed, cheat.
Too soon old, too late smart.

https://sites.google.com/site/myoldlayouts/
https://www.flickr.com/photos/149926300@N07/albums

User avatar
Steve Bennett
Millegniumer
Millegniumer
Posts: 4512
Joined: Sat May 17, 2003 12:55 am
Location: Exeter, UK
Interests: railways?

Postby Steve Bennett » Sun May 17, 2009 11:56 am

chris69 wrote:Do you think it will work with the PECO On30 track


No real need to double up the ties/sleepers with Peco On30, they are wider than the Micro Engineering ones and they would look very odd :lol:
Steve Bennett
Sidelines
http://www.pepper7.com

User avatar
chris69
Demi-Millegniumer
Demi-Millegniumer
Posts: 561
Joined: Sat Aug 11, 2007 7:06 pm
Location: BERLIN Germany
Interests: any thing with narrow gauge and quarries

Atlas track

Postby chris69 » Sun May 17, 2009 5:43 pm

Hi,
well you guys got my 2 brain cells working.Here is my attempt to make cheap track look better.

I took regular Atlas flex track.a piece left over cut the connectors removed some ties and pushed the rest to 1" centers.

Not bad for a cheap fix.Definitely better then the HO track I started with.Too bad I have glued the track on my test layout down.Oh well,next time.


Atlas Code 100 Flex on top,my creation on the bottom.

Greetings
Chris
